Funct i on and f eat ure
Upon customers’ requirements, by adopting assembly robot, manual
welding robot and supporting equipment, robot and assembly line is
integrated through computer technology, machine version technology,
intelligent sensing technology and network technology, in order to form
complicated unmanned automatic electronic assembly system. Due to
systems’ high intelligence, the uniform assembly with high efficiency canbe achieved
Our soldering robot is intelligent, flexible, safe and highly efficient.
Getting more and more sophisticated through continuous development,
our automatic robot has been widely used in the industries of
communication, household electrical appliance, electric appliance,
toy, photoelectricity and automobile manufacturing etc. Our newly
invented inline automatic soldering robot has already been used in the
production of air conditioning remote controller. Our robot has helped
manufacturers realize intelligent production and automatic soldering.
The practical cases about automatic soldering robot in production line
are as follows.
Case 1 Automatic soldering assembly line for air conditioning remote controller
Syst em st ruct ure
A desktop dual tip manual soldering robot, assemblyline fixture and circuit board fixture.
System feature
In order to keep up with the production pace of 700/PCE/HR, an
automatic soldering machine with two soldering torches is used while
fixture assembly line is installed on the table. In this production line,
there is only one operator in charge of pick and placement of fixture at
two sides of the machine. In this case, it saves the time for operator to
push and move the fixture. All parts used by the machine are strictly
checked by us so as to ensure the stability of movement. Since the
soldering robot was put into the production line, good soldering effect
with accurate positioning has been achieved and retained.
System value
In this case, the soldering robot has totally replaced operator in
charge of manual soldering. Four workers in this production line has
been saved. Only one worker is needed to operate the soldering in air
conditioning remote controller. This production line is one of small-
sized production line. It’s recommended that such type of soldering
robot should be used if customer requires high yield but with limitedbudget.
